30*20mm piezo buzzer DX-3020TD12PA

Product Categories
Changzhou Duoxing Electronics Co,.Ltd
Contact Now

30*20mm piezo buzzer DX-3020TD12PA

  • 1
  • 2

Place of Origin : China

Brand Name : DX

Model Number : DX-3020TD12PA

Certification : ROHS/ISO9001:2008

Price : FOBShanghai USD0.50/pc

Packaging Details : Carton

Delivery Time : 15 Days after receiving your payment

Payment Terms : T/T,L/C

Supply Ability : 3000000pcs per month

MOQ : 3000pcs

Contact Now

Diameter 30mm Height 20mm 12V buzzer DX-3020TD12PA

contact with us :yxl(at)duoxin(dot)com

SPECIFICATION

No.

Item

Unit

Specification

Condition

1

Operating Voltage range

Vp-p

3.0 ~ 20.0VDC

2

Rated Voltage

Vp-p

12.0

Volts D.C

3

Rated Current

MA

Max.30

4

Sound Pressure level

dB

Min.100dB

at 30cm at Rated Voltage

5

Frequency of output

Signal

HZ

3500± 500

Square Wave

6

Operating Temp

℃

-20℃～80℃

7

Storage Temp

℃

-30℃～100℃

8

Dimension

mm

Φ30*H20

See appearance drawing

9

Outer CoveringMateeial

PPORoHS

30*20mm piezo buzzer DX-3020TD12PA

30*20mm piezo buzzer DX-3020TD12PA
